DAT 5OO R-T-Z Applanation Tonometer

DAT 5OO R-T-Z Applanation Tonometer


Screws needed to mount the pin adaptor   SL3TMZ and SL209
M3-0.5 x 16 mm  or M3-0.5 x 12 mm

Tonometer Type R
This tonometer is intended to be frequently used.

  1. Characteristics of assembly:

    • stationary, it can be moved when it is not used,

    • mounted above the slit lamp,

    • can be installed at the same time on a Haag Streit and Zeiss type slit lamp



Tonometer Type T
This tonometer is intended to be used occasionally.

  1. Characteristics of assembly:

    • mobile, it must be removed when it is not used,

    • mounted on the lower part of the slit lamp,

    • can be installed at the same time on a Haag Streit and Zeiss type slit lamp.


Tonometer Type Z

This tonometer is intended to be frequently used.

Characteristics of assembly:

stationary, it can be moved when it is not used, mounted above the slit lamp,
can be installed only on a Zeiss type slit lamp.
